The Blustream MFP62 presentation switcher gives meeting spaces a cleaner, more capable way to handle mixed source devices without constant cable swapping or display headaches. This Blustream MFP62 presentation switcher combines six input formats, dual HDMI outputs, 4K UHD 60Hz 4:4:4 support, and built-in audio tools to keep boardrooms, classrooms, and hybrid work environments running smoothly.

Bring multiple source devices together with less friction

When a room needs to accommodate laptops, legacy hardware, and modern USB-C devices, this switcher keeps presentations moving. It lets you connect HDMI, USB-C, DisplayPort, and VGA sources to dual HDMI displays, so it is much easier to manage changing presenters and mixed equipment in one professional setup.

• 3 x HDMI, 1 x USB-C, 1 x DisplayPort, and 1 x VGA input
• Routes sources to dual HDMI outputs
• Supports USB-C up to 4K UHD 60Hz 4:4:4 with DP1.2 and Alt mode
• Supports DisplayPort up to 4K UHD 60Hz 4:4:4, DP1.2
• 1U rack-mountable chassis with rack ears included

Sharp 4K switching with output scaling for reliable display integration

This switcher is built to keep image quality looking polished across compatible displays, with support for high-bandwidth 4K signals and HDR. Dual HDMI outputs with video scaling help simplify integration when displays have different requirements, which is especially useful in shared presentation spaces.

• Supports HDMI 2.0 18Gbps specification including HDR
• Supports resolutions up to 4K UHD 60Hz 4:4:4
• Dual HDMI outputs with video scaling
• HDCP 2.2 compliant with advanced EDID management

Integrated audio control for clearer room performance

Beyond video switching, the MFP62 gives you practical audio flexibility for presentations and collaborative spaces. Audio mixing, microphone support, embedding, and de-embedding make it easier to feed room audio systems, capture spoken content clearly, and adapt the system to the needs of the space.

• Audio mixer with independent level adjustment
• MIC input supports line level, 48V/0.5mA phantom power, or 1-channel balanced / un-balanced audio
• Analogue audio embedding
• Audio breakout to analogue L/R audio and coaxial (S/PDIF) digital outputs concurrently
• Analogue left / right audio input via 3.5mm stereo jack

Flexible control for professional installations

Day-to-day operation is straightforward, while deeper system integration is ready for more advanced installs. With front panel access, remote options, network control, and a built-in web interface, it can fit neatly into managed AV environments where dependable control matters.

• Web interface module for control and configuration
• Control via front panel, IR, RS-232, and TCP/IP
• Includes remote control and IR receiver
• Micro USB port for product upgrades

Frequently Asked Questions

1. Can this switcher connect both modern and older presentation devices? Yes. It supports HDMI, USB-C, DisplayPort, and VGA inputs in one unit.
2. Does it support 4K at 60Hz? Yes, it supports up to 4K UHD 60Hz 4:4:4.
3. Can it feed two HDMI displays at once? Yes, it features dual HDMI outputs with video scaling.
4. Is there built-in microphone support? Yes. The MIC input supports line level, phantom power, and balanced or un-balanced audio.
5. Can it be integrated into a control system? Yes, control is available via front panel, IR, RS-232, TCP/IP, and web GUI.
